Panel Brand:SHARP
Panel Model:LQ10D131
Panel Type:a-Si TFT-LCDPanel
Panel Size:10.4"
Resolution:640(RGB)×480 (VGA)
Display Mode:TN, Normally White, Transmissive
Surface:Antiglare (Haze 25%), Hard coating (2H)
Brightness:70 cd/m2 (Typ.)
Contrast Ratio:60 : 1 (Min.) (Transmissive)
Display Colors:4096 (4-bit)
Response Rime:30/50 (Typ.)(Tr/Td) (ms)
Viewing Angle:35/35/10/30 (Typ.)(CR?10) (L/R/U/D)
Lamp Type:CCFL
Signal Interface:Parallel RGB (1 ch, 4-bit)
Input Voltage:5.0V (Typ.)(VCC)
