New 11.0" LQ110Y3DG01 LCD Industrial LCD Display Screen 800*480New 11.0" LQ110Y3DG01 LCD Industrial LCD Display Screen 800*480

New 11.0" LQ110Y3DG01 LCD Industrial LCD Display Screen 800*480

$155.99
LCD-SHARP-300110-ZKL-010

Quantity Discount
5 +
$148.19
10 +
$145.07
15 +
$141.95
20 +
$140.39
30 +
$137.27
*The discount will be reflected in the payment.
  • Shipping Weight: 1.5kg
  • Units in Stock : 1000
  • Manufactured by: Sharp
  • This product was added to our catalog on Wednesday 09 January, 2013.
Description

Panel brand: Sharp
Panel model: LQ110Y3DG01
Panel type: a-Si TFT-LCD, LCD screen
Panel size: 11.0"(inches)
Width Height Rate: 15:9
Display Area: 240.0mm(H)x144.0mm(V)
Resolution: 800*480
The display mode: TN, Normally white, transmission type
Surface treatment: Matte, hard-core coating (3H)
Panel brightness: 380 CD/㎡(Typ.)
Contrast: 250:1 (Typ.)
Display color: 262K (6-bit)
Response Time:30/50 (Typ.) (Tr/Td) (ms)
Visual Angle: 65/65/55/65 (Typ.) (CR p 10) (L/R/U/D)
Connector: Parallel RGB (1 ch, 8bit)
Panel voltage: 5.0 V (Typ.)

Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
