LQ104V1DG61 10.4" LCD Panel 640*480 TFT Screen For Industrial Application

$249.99
LCD-SHARP-300109-ZKL-021

Quantity Discount
5 +
$237.49
10 +
$232.49
15 +
$227.49
20 +
$224.99
30 +
$219.99
*The discount will be reflected in the payment.
  • Shipping Weight: 1kg
  • Units in Stock : 999
  • Manufactured by: Sharp
  • This product was added to our catalog on Wednesday 09 January, 2013.
Description

Panel Brand: Sharp
Panel Model: LQ104V1DG61
Panel Type: a-si TFT-LCD,LCD Screen
Panel Size: 10.4 inch
Active Area: 211.2×158.4mm
Outline Dimensions: 246.5×179.4×13.7mm
Resolution: 640*480
Contrast: 600:1
Display Mode: TN,Normally white,transmissive
Brightness: 450 cd/㎡ (Typ.)
Contrast Ratio: 350:1(Typ)
Response Rime: 10/25(Typ.)(Tr/Td)
Viewing Angle: 50/60/70/70 (Typ.)(CR≥10) (L/R/U/D)
Backlight: 2×CCFL
Input Interface: TTL-6bit RGB
Operating Temperature: -30~80℃
Appllication: Industrial application.
