4.3 inch LMS430HF08 LCD Display Screen 480*272 LCD Panel4.3 inch LMS430HF08 LCD Display Screen 480*272 LCD Panel

4.3 inch LMS430HF08 LCD Display Screen 480*272 LCD Panel

$78.99
LCD-SAM-300110-ZKL-027

Quantity Discount
5 +
$75.04
10 +
$73.46
15 +
$71.88
20 +
$71.09
30 +
$69.51
*The discount will be reflected in the payment.
  • Shipping Weight: 0.5kg
  • Units in Stock : 1000
  • Manufactured by: Samsung
  • This product was added to our catalog on Wednesday 09 January, 2013.
Description

Panel brand: Samsung
Panel model: LMS430HF08
Panel type: a-Si TFT-LCD, LCD screen
Panel size: 4.3" (inch)
Display Area: 337.9mm x 270.3mm
Width Height Rate: 4:3
Resolution:480*272
The display mode: PVA, Normally black, TMR
Surface treatment: Matte, hard-core coating (3H)
Panel brightness: 400 cd/㎡(Typ.)
Contrast: 800:1 (Typ.)
Display color: 16.7M   (8-bit)
Response Time: 17/15(Typ.) (Tr/Td)(ms)
Visual Angle: 80/80/80/80(Typ.) (CR ≧ 10) (L/R/U/D)
Lamp Type: 10S1P WLED
Singal Type: Parallel RGB (1 ch, 8bit)
Panel voltage: 2.5/3.3V (Typ.)
