12.1" LB121S03 LB121S01 LB121S02 LCD Panel 800*600

$183.89  $89.99
Save: 51%

Quantity Discount
5 +
$85.49
10 +
$83.69
15 +
$81.89
20 +
$80.99
30 +
$79.19
*The discount will be reflected in the payment.
  • Shipping Weight: 1kg
  • Units in Stock : 1000
  • Manufactured by: LG/Philips
  • This product was added to our catalog on Friday 11 January, 2013.
Description

Panel brand: LG
Panel model: LB121S03
Compatible Model:LB121S01 LB121S02
Panel type: a-Si TFT-LCD
Panel size: 12.1"(inches)
Resolution:800*600
Display mode: TN, Normally white, transmission type
Surface treatment: Matte, hard-core coating (3H)
Panel Brightness: 450 cd/㎡(Typ.)
Contrast: 800:1 (Typ.)
Display Color: 262K/16.7M   (6-bit + Hi-FRC)
Response Time: 10/20 (Typ.) (Tr/Td) (ms)
Visual Angle: 70/70/55/65 (Typ.) (CR ≧ 10) (L/R/U/D)
Scanning Frequency:60Hz
Lamp Type: WLED
Singal Connector: LVDS (1 ch, 6/8-bit)
Panel voltage: 3.3V (Typ.)

Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
