Original SX21V001-Z4 HITACHI Screen 8.2" 640×480 SX21V001-Z4 Display

$233.00
HITACHI-LHX-504020-07

Quantity Discount
5 +
$221.35
10 +
$216.69
15 +
$212.03
20 +
$209.70
30 +
$205.04
*The discount will be reflected in the payment.
  • Shipping Weight: 1.5kg
  • Units in Stock : 1000
  • Manufactured by: Hitachi
  • This product was added to our catalog on Sunday 19 April, 2015.
Description

Panel Brand:HITACHI
Panel Model:SX21V001-Z4
Panel Type;CSTN-LCDPanel
Panel Size:8.2"
Resolution:640(RGB)×480 (VGA)
Display Mode:STN, Transmissive
Surface:Antiglare, Hard coating (3H)
Brightness:70 cd/m2 (Typ.)
Contrast Ratio:50 : 1 (Typ.) (Transmissive)
Display Colors:Color
Response Rime:190/160 (Typ.)(Tr/Td) (ms)
Viewing Angle:40 (Typ.)(?2-?1)(CR?2) (L/R/U/D)
Frequency:120Hz
Lamp Type:CCFL
Signal Interface:Parallel Data (8-bit)
Input Voltage:3.3V (Typ.)
