Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 DisplayOriginal C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 DisplayOriginal C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display

Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display

$119.00
LED-AUO-LHX-504030-03

Quantity Discount
5 +
$113.05
10 +
$110.67
15 +
$108.29
20 +
$107.10
30 +
$104.72
*The discount will be reflected in the payment.
  • Shipping Weight: 1.5kg
  • Units in Stock : 1016
  • Manufactured by: AUO
  • This product was added to our catalog on Wednesday 29 April, 2015.
LED-AUO-LHX-504030-03

Description


Panel Brand:AUO
Panel Model:C070VW04 V1
Panel Type:a-Si TFT-LCDPanel
Panel Size:7.0"
Resolution:800(RGB)×480 (WVGA)
Display Mode:AMVA, Normally Black, Transmissive
Surface:Antiglare
Brightness:450 cd/m2 (Typ.)
Contrast Ratio:1500 : 1 (Typ.) (Transmissive)
Display Colors:262K (6-bit)
Response Rime:10/25 (Typ.)(Tr/Td) (ms)
Viewing Angle:80/80/80/80 (Typ.)(CR?10) (L/R/U/D)
Frequency:60Hz
Lamp Type:WLED
Signal Interface:Parallel RGB (1 ch, 6-bit)
Input Voltage:3.2/12.5/15/-9V (Typ.)(VDD/AVDD/VGH/VGL)

Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display
Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display
Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display
